Features
![](/web/image/2429-cafbd999/01feature.jpg)
A standard LED-flashing-stripe-display unit, which functions bar length, bar material change, alarm display while feeding/machining being easy to monitor ( patented).
![](/web/image/2407-f73fde4d/stg03.png?access_token=db36652e-850b-411d-9228-9bbab81119fe)
A hi-end PLC controller is with completed software concept and module-assembly electrical cabinet.
![](/web/image/2409-5582b524/stg04.png?access_token=4a638078-d24c-456e-9d25-52c9a3f5d452)
A HMI display unit functions international languages being easy to set up, user friendly, showing alarm message to troubleshoot.
![](/web/image/2405-95e63618/stg05.png?access_token=6e7a0dca-86b3-413c-a96b-f3431bc83bdc)
A loading system features speed, accuracy, and simple.
![](/web/image/2404-94bf825b/stg06.png?access_token=b425c3fa-ba44-4771-b644-31c4f458fb8f)
An anti-vibration-roller set easily adjust for bar material changeover.
![](/web/image/2410-4c919445/stg07.png?access_token=430800ac-c4c0-4660-ac73-8f86f4ab7520)
A remote control box is durable and conforms with ergonomics.
![](/web/image/2406-9209ef3a/stg08.png?access_token=1a399f4e-5133-4b4e-ad8c-b28449ac8485)
PU guide channel sets of BWG model are easy & quick to changeover.
![](/web/image/2408-f7308c86/stg09.png?access_token=43d5165e-954c-43f4-842a-51e30d37b06b)
A power metallurgy made guide channel set performs durably. (optional)
Specifications
Model |
STG
|
Specifications |
2.5M,3.0M
|
Pu Guide Channel |
11mm,14mm,17mm,19mm,21mm,23mm,25mm
|
Bar Diameter |
3~10mm,3~13mm,3~16mm,4~18mm,5~20mm,5~22mm,5~23mm
|
Steel Guide Channel |
11mm,13mm,17mm,21mm
|
Bar Diameter |
3~10mm,3~12mm,3~16mm, 5~20mm
|
Bar Capacity |
10mm(3/8”)X22pcs
|
Bar Length |
2.5M:2700mm,3.0M:3200mm
|
Machine Weight |
2.5M-270Kg,3.0M-320Kg
|
Air Pressure |
6Kgf/ cm² 70psi
|
Transmission |
SERVO MOTOR
|
Lubricant |
FK ISO VG68,FK HYDRAULIC OIL 68
|
Capacity |
30L(7.5 GALLON)
|
Power Consumption |
630W
|
Powre Supply |
3Φx220V/50/60Hz
|
