Features
![](/web/image/2423-711c0f5f/VITO56-0.png?access_token=7a2d9b68-2556-49d5-8ad2-dde3c6c369ed)
A standard LED-flashing-stripe-display unit, which functions bar length, bar material change, alarm display while feeding/machining being easy to monitor ( patented).
![](/web/image/2424-cf095909/VITO56-1.png?access_token=8ea252ca-67ae-40e4-b560-ef55948df9e6)
A HMI display unit functions international languages being easy to set up, user friendly, showing alarm message to troubleshoot.
![](/web/image/2427-b5211410/VITO56-2.png?access_token=0993aa81-0451-498b-93a9-b5445bf37c13)
Free adjustment of clamping device while bar material is changed.
![](/web/image/2425-7ba90a77/VITO56-3.png?access_token=e770f07b-1668-40df-8040-8cdc6ce18524)
A V-shape anti-vibration device ( bush pairs) is one size to fit all in terms of economy and efficiency.
![](/web/image/2426-0f7135b4/VITO56-4.png?access_token=51032fc8-ac08-47f4-8407-55ef2f06320e)
A mobile remote control box is user friendly to operate with.
![](/web/image/2428-50c57e3a/VITO56-5.png?access_token=1c3c6c90-baa6-48bd-b008-3ef9783f4198)
A hi-end PLC controller is with completed software concept and module-assembly electrical cabinet.
Specifications
Model |
VITO
|
Specifications |
2.5M , 3.0M , 3.6M
|
Guide Channel |
21mm, 27mm,33mm,37mm,39mm,43mm,46mm,52mm,57mm
|
Bar Diameter |
5-20mm,5-26mm,5-32mm,5-36mm,5-38mm,5-42mm,5-45mm,8-51mm,8-56mm
|
Bar Capacity |
10mm/26 pcs
|
Bar Length |
2700mm,3200mm,3800mm
|
Machine Weight |
2.5M – 860kg , 3.0M – 950kg , 3.6M – 1060kg
|
Air Pressure |
6 kgf / cm² 70psi
|
Transmission |
SERVO MOTOR
|
Lubricant |
FK ISO VG68/ FK HYDRAULIC OIL68
|
Capacity |
38L (10 GALLON)
|
Power Consumption |
810W
|
Power Supply |
3 X 220V 50/60Hz
|
